The K-Tech DDS "Lite" rear shock has been designed for use at the highest level of racing and developed in major championships around the world. Like all other K-Tech products it has been designed and manufactured in the UK using the latest design software and highest grades of materials. As you would expect from a high-quality racing product, the DDS "Lite" features compression and rebound damping adjustment, length adjustment and hydraulic spring preload adjustment. The DDS system uses a smaller piston rod which keeps the system more stable over a wider temperature range due to its small displacement. Damping is controlled by a 32mm piston which allows the use of larger shims for improved feel.
- 4 way adjustable
- 32 clicks compression adjustment
- 32 clicks rebound adjustment
- Manual Spring preload adjustment
- Length adjustment
- CNC machined components
- DDS technology
- Potentiometer mounting points
- Wide range of spring rates available
- Used at the highest levels of racing including British Superbike and Isle of Man TT
| SKU | 245-020-010-010 |
|---|---|
| Salable Check | 1 |
| Commodity Code | 87141090 |
| Weight (Kgs) | 4.5 |
| Upper Mount Type | Eye |
| Lower Mount Type | Eye |
| SKU Barcode | 5056106174539 |
| Compression Clicks | 12 |
| Force (N) | 140.00 |
| Preload (mm) | 5 |
| RCU Body Diameter (mm) | 35.00 |
| Lower Mount Bolt Diameter (mm) | 10.00 |
| RCU Rod Diameter (mm) | 12.00 |
| Rebound Clicks | 12 |
| Brand | K-Tech |
| Upper Mount Width (mm) | 23.00 |
| Upper Mount Bolt Diameter (mm) | 10.00 |
| Lower Mount Width (mm) | 23.00 |
| Weight Lbs | 9.92 |
| Rcu Lbolt Dia Inches | 0.39 |
| Rcu Bodydia Inches | 1.37 |
- Availability:
- STG Part Number:
- K|1710-245-020-010-010|0
- Manufacturer's Part Number:
Other Details
Department
Suspension
Manufacturer
Aprilia
Product
Shock
